Roll up side panels for existing timber structure at a school. Provides protection from all weather conditions to create an enclosed outside play area.
Manufactured in mid blue 680g/m² PVC Coated Polyester with 0.5mm Clear PVC Fabric windows welded in. Extruded aluminium awning rail is attahced to the top of the timber structure and keder is welded along the top edge of each fabric panel. The keder edge then slides inside the channel of the rail forming a smooth continuous waterproof connection between fabric and rail.
Bottom pockets allow for a 50x25mm timber sections to tension the bottom of each panel. The sides are fixed with stainless steel turn buttons (that screw into the timber uprights) allowing the panels to be rolled up when required and secured with straps.
